bearing assembly

The basic part number of the slurry pump bearing assembly is 005, also called rotor assembly. It has a large diameter shaft with a short overhang, minimizing deflection and vibration. Only four through bolts are required to hold the cartridge-type housing in the frame.

It is the main component of the drive end to transmit power to the impeller. The bearing assembly is to connect the pump and motor of a whole complete working system. Its stability will directly affect the pump working and pump service life.

Our slurry pump bearing assemblies are available to suit AH pumps, L pumps, M pumps, HH pumps, G and GH pumps.

Bearing Assembly	Pump Models
B005M	1.5/1B-AH, 2/1.5B-AH slurry pump
BSC005M	50B-L slurry pump
C005M	3/2C-AH slurry pump
CAM005M	4/3C-AH, 75C-L, 1.5/1C-HH slurry pump
D005M	4/3D-AH slurry pump
DAM005M	6/4D-AH, 3/2D-HH, 6/4D-G slurry pump
DSC005M	100D-L slurry pump
E005M	6/4E-AH, 8/6E-G slurry pump
EAM005M	8/6E-AH, 10/8E-M, 4/3E-HH slurry pump
ESC005M	150E-L slurry pump
F005M	10/8F-G slurry pump
FAM005M	10/8F-AH, 12/10F-AH, 14/12F-AH slurry pump
FG005M	6/4F-HH slurry pump
G005M	12/10G-GH, 14/12G-G slurry pump
GG005M	12/10G-G slurry pump
R005M	8/6R-AH, 10/8R-M slurry pump
SH005M	10/8ST-AH, 12/10ST-AH, 14/12ST-AH slurry pump
S005M	300S-L, 350S-L, 400ST-L, 450ST-L slurry pump
S005-1M	10/8S-G slurry pump
S005-3M	10/8S-GH slurry pump
T005M	550TU-L, 650TU-L slurry pump
T005-1M	14/12T-AH, 14/12T-G, 18/16T-G slurry pump
TH005M	16/14TU-AH, 16/14TU-GH slurry pump
